Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Maintenance 01/2011 Page 439
SHEET E-12STANDARD REPLACEMENT OF AN AXL MAIN CABINET
AVAILABILITY
• No mission capable
• 1 operator on site
DURATION
• 20 minutes
INGRÉDIENT(S)/CONSOMMABLE(S)
•N/A
Table 19:
OPERATION DETAILS OF THE OPERATION / COMMENTS
• Back up the customer
configuration.
• Precautionary operation to be carried out if there is no existing
copy (which is the case when previous installation operations
have been carried out and the procedures followed).
• Refer to [1]
• In the case of remote operation, contact the remote operator
before starting any operation.
• Power off the iPBX. • Refer to Section 6.4, Stopping the system (AXD, AXL, AXS,
AXS12 and AXS6)Error! No bookmark name given.
• For a system with several cabinets, first power off the main
cabinet, then the expansion cabinet.
Nota : It is advisable to stop the IPS card before powering off the
iPBX.
• Disconnect the cables. • Disconnect the mains cable.
• Disconnect the cables from the front panel of the UCV card and
those on the cabinet's expansion cards and mark the cables for
refitting.
• For a system with several cabinets, disconnect the cable located
at the rear of the cabinet.
• Remove the old cabinet.
• Remove the UCV card. • Pull out the UCV card from its slot using
the 1/4 turn locks (see Figure 4.1 ).
• Retrieve the module.
i-Button.
• Recover, on the UCV card, the i-button module containing the
system's identifier.
• Remove the new UCV
card.
• Pull out the new UCV card from its slot using the 1/4 turn locks
(seeFigure 4.1 ).
• Install the module.
i-Button.
• Install the i-button module from the old UCV card on the new
card.
