Section D Graphic Display
D-87
D 7.5.3 Points
The construction points of the graphic objects polyline and polygon can be moved or deleted.
Delete
→Select graphic object polyline or polygon,
→Change → Points → Delete
→Click the point to be deleted, the graphic object remains selected and is redisplayed in
the altered form.
Move
→Select graphic object polyline or polygon,
→Change → Points → Move
→Click the point to be moved and move it to the desired position with left mouse button
pressed. (The frame disappears).
→Releasing the left mouse button completes the action. The graphic object remains
selected and is displayed with the shifted points.
D 7.5.4 Text edit
→Change → Text edit.
Selected texts can be altered. An input window with the existing text appears in which text can be
added or deleted. The text attributes are not effected.
If a combined graphic object contains several texts, the texts are presented for modification one
after the other.
