132 Parameters
b4: Master/Follower 1 = Tick received: Tick is received through the
master/follower link.
b5: Reserved -
b6: D2D 1 = Tick received: Tick is received through the inverter-
to-inverter link.
b7: FbusA 1 = Tick received: Tick is received through fieldbus
interface A.
b8: FbusB 1 = Tick received: Tick has been received through
fieldbus interface B.
b9: EFB 1 = Tick received: Tick was received through the
embedded fieldbus interface.
b10: Ethernet 1 = Tick received: Tick was received through the
Ethernet port on the BCU control unit.
b11: Panel link 1 = Tick received: Tick is received from the control
panel, or Drive composer PC tool connected to the
control panel.
b12: Ethernet tool link 1 = Tick received: Tick is received from Drive composer
PC tool through an FENA-xx module.
b13 Parameter setting 1 = Tick received: Tick is set by parameters
196.24…196.26.
b14 RTC 1 = RTC time in use: Time and date is read from the
real-time clock.
b15 Drive On-Time 1 = Inverter on-time in use: Time and date are displaying
inverter on-time.
196.61 User data logger status
word
Shows the status of user data logger.
This parameter is read-only.
0x0000/
Bit list
b0: Running User data logger is running. This bit is cleared after post
trigger time has passed.
b1: Triggered User data logger has triggered. This bit is cleared when
user data logger is re-started.
b2: Data available Data logger contains data that can be read. Note: this bit
is not cleared after it has risen because triggered data is
saved into ZMU.
b3: Configured User data logger configured. Note: this bit is not cleared
after it has risen because configuration data is saved
into ZMU.
b4 … b15: Reserved
196.63 User data logger trigger Activates bit pointer to trigger user data logger Off/ List
Off User data logger not triggered. 0
On User data logger triggered. 1
Other See Terms and abbreviations on page 57. -
196.64 User data logger start Activates bit pointer to start user data logger. Off/ List
Off User data logger not started. 0
On User data logger started. 1
Other See Terms and abbreviations on page 57. -
196.65 Fault data logger time
level
Selects time level of fault data logger. When fault data
logger is made to sample on a slower time level, data
may be captured from a longer time period.
500us/ Real
500us Factory data logger runs at 500us time level. Data is
captured approximately for the set time period.
0
No. Name/Value Description Def/
FbEq16/32
