Parameters 131
User set 2 User set 2 is loaded. 5
User set 3 User set 3 is loaded. 6
User set 4 User set 4 is loaded. 7
User set 5 User set 5 is loaded. 8
User set 6 User set 6 is loaded. 9
User set 7 User set 7 is loaded. 10
User set 8 User set 8 is loaded. 11
196.20 Time synchronization
source
Defines first priority source for synchronizing date and
time of the inverter from an external source.
DDCS
Controller/
List
Internal No external time synchronization for date and time of the
inverter.
0
DDCS Controller AC800M automation PLC through CI858, Module bus. 1
Fieldbus A or B Fieldbus channel A or B. 2
Fieldbus A Fieldbus channel A. 3
Fieldbus B Fieldbus channel B. 4
D2D or M/F D2D-communication master, or master in
master/follower link.
5
Embedded FB Embedded fieldbus 6
Embedded Ethernet Ethernet port in BCU. 7
Panel link User’s panel e.g. ACS-AP-I or inverter composer-tool. 8
Ethernet tool link Drive Composer PC tool Ethernet link. 9
196.24 Full days since 1st Jan
1980
Sets day count starting from 1st January 1980.
This parameter, together with 196.25 Time in minutes
within 24 h and 196.26 Time in ms within one minute
makes it possible to set the date and time in the inverter
via the parameter interface from a fieldbus or application
program. This may be necessary if the fieldbus protocol
does not support time synchronization.
12055 days/
Real
1 … 59999 days Days since beginning of 1980. 1 = 1 days
196.25 Time in minutes within
24 h
Sets the number of full minutes passed since midnight.
For example, the value 860 corresponds to 2:20 pm.
See parameter 196.24 Full days since 1st Jan 1980.
0 min/ Real
0 … 1439 min Minutes since midnight. 1 = 1 min
196.26 Time in ms within one
minute
Sets the number of milliseconds passed since last
minute.
See parameter 196.24 Full days since 1st Jan 1980.
0 ms/ Real
0 … 59999 ms Number of milliseconds since last minute. 1 = 1 ms
196.29 Time source status Shows the status and priority of active time source.
This parameter is read-only.
0b0000/
Bit list
b0: Time tick received 1 = 1st priority tick received: Tick was received from 1st
priority source.
b1: Aux Time tick
received
1 = 2nd priority tick received: Tick was received from
2nd priority source.
b2: Tick interval is too
long
1 = Yes: Tick interval too long (accuracy compromised).
b3 DDCS controller 1 = Tick received: Tick is received from an external
controller.
No. Name/Value Description Def/
FbEq16/32
