74 Parameters
Min phase rms voltage Minimum rms value of phase voltage. 3
Pos seq voltage Positive sequence component of voltage. 4
126.03 Lv Rt asymm sig Selects voltage signal of low voltage asymmetric dip. Pos seq
voltage/
List
Max LL rms voltage Maximum rms value of line-to-line voltage. 0
Min LL rms voltage Minimum rms value of line-to-line voltage. 1
Max phase rms voltage Maximum rms value of phase voltage. 2
Min phase rms voltage Minimum rms value of phase voltage. 3
Pos seq voltage Positive sequence component of voltage. 4
126.04 Hv Rt symm sig Selects voltage signal of high voltage symmetric dip. Max phase
rms voltage/
List
Max LL rms voltage Maximum rms value of line-to-line voltage. 0
Min LL rms voltage Minimum rms value of line-to-line voltage. 1
Max phase rms voltage Maximum rms value of phase voltage. 2
Min phase rms voltage Minimum rms value of phase voltage. 3
Pos seq voltage Positive sequence component of voltage. 4
126.05 Hv Rt asymm sig Selects voltage signal of high voltage asymmetric dip. Max phase
rms voltage/
List
Max LL rms voltage Maximum rms value of line-to-line voltage. 0
Min LL rms voltage Minimum rms value of line-to-line voltage. 1
Max phase rms voltage Maximum rms value of phase voltage. 2
Min phase rms voltage Minimum rms value of phase voltage. 3
Pos seq voltage Positive sequence component of voltage. 4
126.06 Asymm/symm limit Defines negative sequence voltage level when the dip is
considered as asymmetric dip.
3%/ Real
0 … 100% Asymmetric dip limit 1 = 1%
126.10 Lv Rt trig U % Activates low voltage tripping curve function if the mains
voltage is below the trig level.
85%/ Real
0 … 100% Low voltage tripping curve trig level. 1 = 1%
126.11 Lv Rt recover hyst U % Defines low voltage tripping curve function recover
hysteresis. The curve is deactivated when mains voltage
is above the trigger limit plus hysteresis.
5%/ Real
0 … 20% Low voltage tripping curve function recover hysteresis. 1 = 1%
126.12 Lv Rt sec 1 time Defines duration of low voltage tripping curve (Lv Rt)
section 1. If duration is greater than zero, the Lv Rt
section is enabled.
600 ms/ Real
0 … 300000 ms Low voltage tripping curve section 1 duration. 1 = 1 ms
126.13 Lv Rt sec 2 time Defines duration of low voltage tripping curve (Lv Rt)
section 2. If duration is greater than zero, the Lv Rt
section is enabled.
600 ms/ Real
0 … 300000 ms Low voltage tripping curve section 2 duration. 1 = 1 ms
126.14 Lv Rt sec 3 time Defines duration of low voltage tripping curve (Lv Rt)
section 3. If duration is greater than zero, the Lv Rt
section is enabled.
600 ms/ Real
0 … 300000 ms Low voltage tripping curve section 3 duration. 1 = 1 ms
No. Name/Value Description Def/
FbEq16/32
