A number of outputs from the function keeps track of the actual state in the auto
reclosing sequence. The outputs are:
• INPROGR: any dead time is in progress
• 1PT1, 2PT1, 3PT1, 3PT2, 3PT3, 3PT4 and 3PT5: dead time is in progress for
respective shot and fault type
• ACTIVE: during dead time + reclaim time
• COUNTAR: total number of auto reclosing shots
• COUNT1P, COUNT2P, COUNT3P1, COUNT3P2, COUNT3P3, COUNT3P4
and COUNT3P5: number of circuit breaker close commands made for
respective shot
• STATUS: reports, only through the IEC 61850 protocol, the actual status of the
function.
The possible statuses are described in Table
204 below. Their mapping to output
signals and their corresponding IEC 61850 integer value is also given in the table.
Mapping from IEC 61850 Ed2 standard is also shown for the AutoRecSt data
object.
Table 204: Auto reclosing status reported by IEC 61850 in priority order
Data object AutoRecSt
value
Description for mapped
signals
Mapped output signals /
Comments
Description in IEC61850
Ed2
1 Ready READY Ready
2 In Progress INPROGR In Progress
3 Successful SUCCL Successful
4 Waiting for trip
5 Trip issued by
protection
6 Fault disappeared
7 Wait to complete CLOSECB Wait to complete
8 Circuit breaker closed
9 Cycle unsuccessful UNSUCCL
10
-1 Aborted by
synchrocheck fail
SYNCFAIL
11 Aborted ABORTED Aborted
-2 Set On, Not Ready SETON = 1, READY =
0, ACTIVE = 0,
SUCCL = 0, UNSUCC
= 0, INPROG = 0
-3 Set Off, Not Ready SETON = 0
-99 Others Means that auto
recloser is in
transitional state, that
should not be visible in
steady state situation
