CELL-DYN
®
3200 System Operator’s Manual
4-3
9140181H—October 2001
Section 4 Performance Characteristics and Specifications
System Specifications
Physical Specifications
Table 4.1 and Table 4.2 contain physical specifications for both the
CELL-DYN 3200SL and CS models.
Table 4.1 Instrument Dimensions
Analyzer SL Analyzer CS
Display
Monitor
Ticket Printer
(Dot Matrix)
Graphics
Printer
(Color Bubble
Jet)
Height
19" (48.2 cm) 19" (48.2 cm) 15" (38.1 cm) 6" (15.2 cm) 7.2" (18.3 cm)
Width
32.8" (83.3 cm) 32.8" (83.3 cm) 14" (35.5 cm) 16.5" (41.9 cm) 16.1" (40.9 cm)
Depth
29.3" (74.4 cm) 23.3" (59.2 cm) 16" (40.6 cm) 14.5" (36.8 cm) 9.9" (25.1 cm)
Weight
232 lb (105.5 kg) 214 lb (97.3 kg) 30 lb (13.6kg) 16.5 lb (7.5 kg) 9.9 lb (4.5 kg)
Table 4.2 Dimensions After Packaging for Shipment
Analyzer SL Analyzer CS
Display
Monitor
Ticket Printer
(Dot Matrix)
Graphics
Printer
(Color Bubble
Jet)
Height
38" (96.5 cm) 38" (96.5 cm) 20" (50.8 cm) 9.5" (24 cm) 12" (30.5 cm)
Width
34" (86.3 cm) 34" (86.3 cm) 18" (45.7 cm) 21" (53 cm) 19.5" (49.5 cm)
Depth
31" (78.7 cm) 31" (78.7 cm) 18" (45.7 cm) 18.5" (46 cm) 14.8" (37.6 cm)
Weight
273 lb (124 kg) 255 lb (116 kg) 37.5 lb (17 kg) 21 lb (9.5 kg) 16.4 lb (7.4 kg)
