Performance Characteristics and Specifications
System Specifications
Section 4
Power Specifications
Table 4.3 shows the power requirements for both the CELL-DYN 3200 SL and CS
models.
Consumption
Analyzer: 900 watts
Monitor: 156 watts
Graphics Printer: 60 watts
1116 watts maximum (3810 BTU per hour)
Transport and Storage Specifications
There are no specific environmental conditions for transport or storage.
Table 4.3 Power Specifications
Analyzer Input Requirements
Module Voltage Frequency Max Current BTU/Hr
Analyzer 110 VAC ± 10%
120 VAC ± 10%
220 VAC ± 10%
240 VAC ± 10%
50/60 ± 3Hz
50/60 ± 3Hz
50/60 ± 3Hz
50/60 ± 3Hz
6 amps
6 amps
3 amps
3 amps
1945
1945
1945
1945
Analyzer &
Sample Loader
110 VAC ± 10%
120 VAC ± 10%
220 VAC ± 10%
240 VAC ± 10%
50/60 ± 3Hz
50/60 ± 3Hz
50/60 ± 3Hz
50/60 ± 3Hz
6 amps
6 amps
3 amps
3 amps
1945
1945
1945
1945
Monitor 100–240 VAC 50/60 Hz 1.3 amps
Printer 120 VAC ± 10%
220 - 260 VAC
50/60 Hz 0.5 amps 205
