Use or Function
System Components
Section 1
Left Side Panel
The only major component on the Left Side Panel is the Fan, shown in Figure 1.6.
Fan
A Fan cools the internal components of the Analyzer.
Figure 1.6 Left Side Panel
1Fan
1
