Technical data of the device
DLT-V83 Operating Instructions V2.00 17 / 157
5.1.8. Device dimensions
DLT-V8310
Dimensions without add-ons (in mm)
Fig. 5.1: Dimensions DLT-V8310
The building depth of the DLT-V8310 varies depending on the type of touchscreen:
Device type Building depth
(Mass X, see figure)
DLT-V8310 standard resistive touchscreen 90,0 mm
DLT-V8310 sunlight readable resistive touchscreen 90,0 mm
DLT-V8310 PCT touchscreen 91,5 mm
DLT-V8310 with screen-defroster front 90,7 mm
