Technical data of the device
18 / 157 DLT-V83 Operating Instructions V2.00
DLT-V8312
Dimensions without add-ons (in mm)
Fig. 5.2: Dimensions DLT-V8312
The building depth of the DLT-V8312 varies depending on the type of touchscreen:
Device type Building depth
(Mass X, see figure)
DLT-V8312 standard resistive touchscreen 93,0 mm
DLT-V8312 sunlight readable resistive touchscreen 94,7 mm
DLT-V8312 PCT touchscreen 96,0 mm
DLT-V8312 with screen-defroster front 94,2 mm
