Technical data on radio modules
DLT-V83 Operating Instructions V2.00 31 / 157
6.3.2. WLAN antenna IEEE 802.11 a/b/g/n/ac
Antenna module (visible with antenna cap open)
Fig. 6.2: WLAN antenna IEEE 802.11 a/b/g/n/ac and antenna module (optional)
Technical data
Application WLAN a/b/g/n/ac Dual Band with MRC
Bluetooth (integrated via Radio card)
WLAN frequency range Band 1: 2400 to 2485 MHz
Band 2: 5150 to 5850 MHz
Bluetooth features
See section 6.4.1 Bluetooth
Number of antennas
2
Available color
Red
Type
Omnidirectional antenna
Antenna gain
Max. 4.44 dBi (without loss through the cable)
Impedance
50 Ω
Polarization
Vertical/horizontal
Maximum transmitting power
100 mW / 20 dBm
Compatible Radio card: SPARKLAN WPEQ-261ACN(BT)
(see section 6.2.1 Available radio cards)
