Interfaces, connectors
40 / 157 DLT-V83 Operating Instructions V2.00
7.2. External
7.2.1. Serial interfaces
COM1 Max. 115,200 Baud (16550A compatible, 16 byte FIFO), supports EIA-
232-E on external 9-pin D-Sub connection
ESD Level 4 protected (according to EN 61000-4-2)
Optional: COM1 with 5 V or 12 V
COM2 Max. 115,200 Baud (16550A compatible, 16 byte FIFO), supports EIA-
232-E on external 9-pin D-Sub connection
ESD level 4 protected (acc. to EN 61000-4-2)
Optional: COM2 as a galvanically isolated EIA-422/485
7.2.2. USB, Service-USB
USB connection,
for example for mouse,
keyboard, USB stick
3 x USB 2.0 Host
USB 2.0 HiSpeed
Fused at 0.5 A per channel
ESD Level 4 protected (according to EN 61000-4-2)
Service USB
e.g. for mouse, keyboard,
USB stick
1 x USB 2.0 Host, Service-connection under antenna cap
USB 2.0 HiSpeed
Fused at 0.5 A per channel
ESD level 4 protected (acc. to EN 61000-4-2)
7.2.3. Audio interface for handset
Audio handset-connection Microphone input
Audio out max. 2 W @ 8 Ohm
ESD Level 3 protected (according to EN 61000-4-2)
7.2.4. Network interface
CPU Intel® Core™ i5-4300U and Intel
®
Celeron
®
2980U
Network controller Intel
®
i218LM Gigabit Ethernet 10/100/1000 MB/s
Network connection RJ45 connector
Integrated carrier
Two integrated status LEDs
Intel
®
Atom™ D525
Network controller Intel
®
82567V Gigabit Ethernet 10/100/1000 MB/s
Network connection RJ45 connector
Integrated carrier
Two integrated status LEDs
