Technical data on radio modules
32 / 157 DLT-V83 Operating Instructions V2.00
6.3.3. WLAN, WWAN 3G
Fig. 6.3: WLAN, WWAN 3G antenna (optional)
Technical data
Application WLAN IEEE 802.11 a/b/g/n Dual Band Diversity
WWAN 3G
WLAN frequency range Band 1: 2400 to 2485 MHz
Band 2: 5150 to 5875 MHz
WWAN frequency range GSM900: 880 to 960 MHz
GSM1800: 1710 to 1880 MHz
GSM1900: 1850 to 1990 MHz
UMTS: 1920 to 2170 MHz
Number of antennas
4
Available colors
Red, gray
Type
Omnidirectional antenna
Antenna gain
Max. 3 dBi (without loss through the cable)
Impedance
50 Ω
Polarization
Vertical/horizontal
Maximum transmitting power WLAN: 100 mW / 20 dBm
WWAN: 250 mW / 24 dBm
Compatible Radio card: SUMMIT/LAIRD SDC-PE15N
(see section 6.2.1 Available radio cards)
Compatible WWAN Radio card: USA: SIERRA WIRELESS MC8090
Europe: SIERRA WIRELESS MC8092
(see section 6.2.2 Available Radio cards)
