Technical data of the device
22 / 157 DLT-V83 Operating Instructions V2.00
Power supply, power consumption, power supply unit fuses
Power supply
DC power pack
12/24/48 VDC
(wide-range power supply
unit)
60 W / 80 W internal
Type DC-16
12/24/48 VDC nominal
Galvanically isolated
Withstands bursts up to 2 kV
Full output power of the 12/24/48 VDC power supply unit for 20
seconds each:
For 6 V: 40 W
For 9 V: 60 W
Rising in linear fashion between the above
Voltage range 9 to 60 VDC
Bridged power failures Typically 2 ms at 12 V
Typically 10 ms at 24 V
Typically 40 ms at 48 V
Maximum output power 60 W (+10 to +70 °C internal device temperature);
or 80 W (-30 to +10 °C internal device temperature)
Nominal current 8.4 A
Connection to SELV circuit
only
The SELV circuit is a secondary circuit that is designed and
protected so that its voltages will not exceed a safe value both
when operating correctly or if a single error occurs.
Power consumption DLT-V83 Intel® Atom™ D525
DLT-V8310 Typically 25 W, Standby typically 1 W
DLT-V8312 Typically 30 W, Standby typically 1 W
DLT-V8315 Typically 30 W, Standby typically 1 W
Power consumption DLT-V83 Intel® Core™ i5-4300U and Intel
®
Celeron
®
2980U
DLT-V8310 Typically 35 W, Standby typically 1 W
DLT-V8312 Typically 40 W, Standby typically 1 W
DLT-V8315 Typically 40 W, Standby typically 1 W
Power supply unit fuses
Power supply unit Fuse type Example
DC-16 5 x 20 mm T
12.5 A
H / 250 V
Schurter 0001.2515
Siba 179200.12,5
or similar produced by other manufacturers
The symbol for the fuse is FA. You will find the exact position on the sticker located on the connection
plate of the DLT-V83.
