BODY FRAME
6-140
FRONT WHEEL AND BRAKE
REMOVE THE FRONT WHEEL
1. Elevate front end of the scooter off the ground to remove
front wheel and brake from front fork.
Severe injury could occur if machine tips or falls.
2. Remove front brake calipers. Do not apply the brake
lever when removing the brake calipers.
3. Remove front wheel axle, nut, speed sensor and spacer
from front fork.
4. Remove front wheel with disc assembly from front fork.
FRONT WHEEL DISASSEMBLY
1. Clean the surface of the front wheel hub .
2. Inspect the axle hub main bearings for worn or damaged.
The bearing must be inspected visually and by turning feel. The
bearing should turn smoothly and quietly.
