MAINTENANCE
2-24
WHEELS AND TIRES
TIRE PRESSURE MEASUREMENT
1. Position the vehicle on a level surface. Use the center stand.
2. Measure tires pressure by gauge and corrected it.
• The tire pressure should only be checked and
regulated when the tire temperature equals the
ambient air temperature.
• The tire pressure and the suspension must be
adjusted according to the total weight (including
cargo, rider, passenger and accessories) and the
anticipated riding speed.
• Operation of an overloaded scooter could cause
tire damage, an accident or an injury.
• NEVER OVERLOAD THE SCOOTER.
Dry weight (Incl. Oil & Fuel) 170 kg
Max Load 200kg
Front tire
Max. Load 230kg/ 584lb.
Tire pressure 210kap/ 30psi.
Max tire pressure 280kpa/ 33psi.
Rear tire
Max. Load 325kg/ 716lb.
Tire pressure 252kpa/ 36psi.
Max tire pressure 280kpa/ 40psi
WEAR INDICATOR
It is dangerous to ride with a worn-out tire.
tire tread reaches the wear limit, replace the tire
immediately.
1. Inspect tire thread depth and side wall surface condition. If
reach worn limit, replace it immediately.
Note: Patching a punctured tire is not recommended.
If tire were patched, replace it.
2. When replacing a tire always use original equipment size
and type.
New tires have a relatively low grip on the road
surface until they have been slightly worn.
Therefore, approximately 100 km should be traveled
at normal speed before any high-speed riding is
done.
There is a direction of rotation mark on tire surface. Install the
tire with the mark pointing in the direction of wheel rotation.
