MAINTENANCE
2-18
FUEL PUMP / FUEL FILTERS / PUMP
REGULATOR
The 350 EFI engine uses a non-serviceable, high-volume,
high-pressure, fuel pump system that includes a filter and a
pump regulator.
NOTE: For all other information related to the EFI
System, refer to Chapter 6.
VENT LINES
1. Check fuel tank, front gear case, rear gear case and
transmission vent lines for signs of wear, deterioration,
damage or leakage. Replace every two years.
2. Be sure vent lines are routed properly and secured with
cable ties.
IMPORTANT: Ensure lines are not kinked or pinched.
THROTTLE INSPECTION
If the throttle has excessive play due to cable stretch or cable
maladjustment, it will cause a delay in throttle speed.
Also, the throttle may not open fully. If the throttle has no
play, the throttle may be hard to control, and the idle speed
may be erratic.
Check the throttle pedal play periodically in accordance with
the Periodic Maintenance Chart and adjust the play if
necessary.
THROTTLE FREE PLAY ADJUSTMENT
Inspection
1. Start the engine, and warm it up thoroughly.
2. Measure the distance the throttle pedal moves before the
engine begins to pick up speed. Free play should be 3 - 5 mm.
Adjustment
1. Squeeze the end of the rubber boot and slide it far enough to
expose the end of the inline cable adjuster.
2. Loosen the adjuster lock nut.
3. Rotate the boot to turn the adjuster until 3-5 mm of freeplay
is achieved at the throttle pedal.
NOTE: While adjusting, lightly pull the throttle lever.
4. Tighten the lock nut.
5. Squeeze the end of the rubber boot and slide it over the
cable adjuster to its original position.
After adjusting the throttle cable free play, start the
engine and turn the handlebars to the right and to
the left to ensure that this
