Aeon 350cc User Manual

GENERAL INFORMATION
1-7
SPECIFICATIONS
MODEL: URNAN 350i
ENGINE DRIVE SYSTEM
Type 4 Stroke, Single horizontal camshaft Gear Box Oil capacity
200 CC
Displacement 313 CC Gear Oil type 80w90
Cooling Liquid cooled Clutch type Dry Centrifugal clutch
Bore and stroke 78 mm *65.6 mm Final drive ratio 40/12*38/13=9.74
Compression ratio 10.4 : 1
Number of valve 2 Rocker arm activated
Inlet valve Ø
ØØ
Ø Ø 33.50mm
Inlet valve clearance 0.10mm CHASSIS
Exhaust valve Ø
ØØ
Ø Ø 30.00mm Frame Steel
Exhaust valve clearance 0.12mm Front suspension Telescope forks
Lubrication Wet sump and pump pressurized Front wheel travel 100mm
Recommended oil 0W/ 40 Rear suspension Swing Arm
Oil capacity 1800 CC Rear wheel travel 135 mm
Starting system Electric start/ DC, CDI Front brake Duel disc with single bore caliper
Max. Power 16.5kw/7500rpm Rear brake Single Disc with single bore caliper
Max. Torque 25Nm/ 4000rpm Front tire 120/70-16, 29psi
FUEL SYSTEM Rear tire 140/70-15, 36psi
Type Electrical Fuel Injection
Fuel Delivery
Electronic Fuel Pump
Fuel Pressure
3 Bar/ 43.5psi DIMENSIONS
Throttle dimensions 30mm Overall length 2175 mm
Fuel Capacity
13.5 Liter Overall width 840 mm
Idle RPM 1500±100 Overall height 1290 mm
Seat height 800mm
Wheelbase 1545mm
ENG. ELECTRICAL Max. Permissible weight
200Kg
Charging system Alternator and voltage regulator Number of passenger 2
Alternator output 168W@4000RPM Min. ground clearance 160mm
Ignition type TDI Dry weight 175Kg
Spark plug type NGK/ DPR7EA-9 Fuel tank capacity 13.5 Liter
Spark plug gap 0.6~0.7mm Max. Speed 120 km/hr
RPM limiter setting 8500 rpm
Battery type GTX10-BS
Fuse type
Charge 30A/ Main 15A/ Light
10A/ Spare 15A
