ENGINE
4-94
5. Remove the gasket & dowel pin.
6. Remove counter gear first.
7. Remove Final shaft and gear.
◎
◎◎
◎ It is not necessary to remove the drive shaft
from the cover upper side.
◎
◎◎
◎ If remove the drive shaft from the gear box
cover which its bearing has to be replaced.
TRANSMISSION INSPECTION
1. With transmission components removed, inspect all shaft
bearings visually and by feel. Bearings should roll smoothly,
without excessive movement or noise. Replace any bearing
that is removed, as the removal process destroys the bearing.
2. Bearings can be removed using a standard blind bearing
remover. Apply lithium grease to outer race of new bearings
and press into cover or case by the outer race. Do not press on
inner race or bearing will be damaged.
DRIVE SHAFT INSPECTION
Inspect the drive shaft and gear visually without excessive
wear or crack. Replace any damaged components.
COUNTER SHAFT / GEAR INSPECTION
Inspect the counter shaft and gear visually without excessive
wear or crack. Replace any damaged components.
