ELECTRICAL
7-189
Step: Heating
Water temperature Continuity
Less than 80 ± 3 °C
(176 ± 5.4 °F)
No
More than 80 ± 3 °C
(176 ± 5.4 °F)
Yes
Step: Cooling
Water temperature Continuity
More than 70 °C
(154.4 °F)
Yes
Less than 67 °C
(153 °F)
No
Handle the thermo switch with special care. Hot
water could severe injury skin and eyes.
Always wearing protection gears.
Never subject it to a strong shock or allow it to be
dropped. Should it be dropped, it must be replaced.
5. If the thermo switch does not continuity, replace it.
Wiring connection
Refer to “CIRCUIT DIAGRAM”. Check the connections of the entire
cooling system. If poor connecting, repair or replace it.
Trouble Shooting
No voltage
Battery discharged.
The cable disconnected.
The fuse is blown.
Improper operation of the main switch.
Low voltage.
The battery is not fully charged.
Poor contact.
Poor charging system.
Poor voltage regulator.
No spark produced by spark plug
The spark plug is out of work.
The cable is poorly connected, open or
short-circuited.
Between AC Generator ECU.
Poor connection between ECU and ignition coil.
Poor connection between ECU and the main
switch.
Bad main switch.
ECU malfunctions.
AC Generator malfunctions.
Starter motor does not work
The fuse is blown.
The battery is not fully charged.
Bad main switch.
Bad starter switch.
The front or rear brake switches does not
function correctly.
Starter relay is out of work.
The ignition coil is poorly connected, open or
short-circuited.
The starter motor malfunctions.
