4.21 Adjusting the Deflectors (only RPC 130 F)
Before starting the procedure
Two deflectors, keep the net in the roll chambers. The two deflectors are installed in the bottom area of the
roll chambers.
The distance between the deflector and the roller is adjustable. To set the distance to the correct position,
do the steps which follow.
Procedure
Set the distance of the deflector from the
roller to 1-3 mm.
a) Loosen the fasteners on the two sides of
the deflector.
b) Set the deflector to the correct distance
from the contour of roller.
c) Tighten the fasteners on the two sides of
the deflector.
GUID-4BFFABD0-B88E-430C-A0C0-3D81C0D450FA-high.jpg [High]
Fig. 33
GUID-8A222FE8-E8CB-4638-8311-9D37E5DE9EF0 [V1]
4. Maintenance and Lubrication
Baler Wrapper Combination 143
4900.LE.EN01
