Procedure
1. Loosen the lock nut.
2. Turn the adjustment screw in or out, refer to
the type of hydraulic system on the tractor.
3. Tighten the lock nut.
GUID-1608CB98-ED73-4368-8F03-44503A211738-high.jpg [High]
Fig. 4
(1)
Manifold
3.1.8 Prepare the Chain Lubrication System
Procedure
1. Fill the oil container.
2. Remove air from the lubrication pump.
Related Links
Fill the Oil Container page 120
Bleed Air from the Lubrication Pump page 121
3.1.9 Adjust the Net Roll Holder
NOTE: Net rolls are available in a selection of widths and net lengths. It is necessary to make adjustments
for the length and the width of the net.
Before starting the procedure
WARNING: Risk of injury.
Before you do work near the net knife, install the net knife safeguard and make the net
knife safe.
GUID-326E7AB2-A241-4FE8-823D-1DF71EC0B728 [V1]
GUID-FBA547F5-72A3-43B0-9D44-3AEAC435C677 [V1]
3. Operation
72 Baler Wrapper Combination
4900.LE.EN01
