3.5.3 Make Two or Three Smaller Bales at the End of the Field
Do this for the last two or three bales on the field
Procedure
1. Stop the tractor when the bale is at the necessary dimensions.
2. Push the button to start tying.
3. Eject the bale.
3.5.4 Make One Larger Bale at the End of the Field
Procedure
1. Make sure that you engage the manual bale tying (to adjust from automatic baling push the button
).
2. Drive the tractor until you collect all the crop material.
3. Stop the tractor.
4. Push the button to start tying.
5. Eject the bale.
3.5.5 Drive Instructions for Material Intake
To get a high intake of crop material and good circular bales, fill the baling chamber equally.
With a good driving style, it will use material from the total width of the pick-up and the baling chamber.
3.5.6 Large Swath
Before starting the procedure
If the swath is wider than the bale chamber:
Procedure
1. Drive at the correct speed (hand throttle).
2. Drive on the centre of the swath, so the swath goes in the centre of the pick-up.
3.5.7 Small Swath
Before starting the procedure
If the swath is smaller than the bale chamber:
Procedure
1. Drive at the correct speed (hand throttle).
2. Fill the baling chamber equally with material without stops (RPC 130 F).
3. Fill the baling chamber equally with material without stops, drive as shown in the schedule that
follows (RPC 160 V).
GUID-B1A7C59C-A51F-4DAC-A19B-D3812A9EDC48 [V1]
GUID-A36488FC-FC90-41AF-A5CE-BE5B237600B4 [V1]
GUID-3A99F156-5E9A-4E4E-8F6B-95CE7DD4A7CF [V1]
GUID-1701D7D7-1EC0-4FAE-8424-B8CCFE3D196B [V1]
GUID-1FFAAC39-3358-4E7C-958A-451D5C0B9991 [V1]
3. Operation
Baler Wrapper Combination 99
4900.LE.EN01
