Agilent 1260 Infinity DAD and MWD User Manual 205
Maintenance
10
Maintenance of Standard, Semi-Micro or Micro Flow Cell
5
Correct orientation of spring washers [2] is required. 6 Press the Teflon® ring into the window assembly.
7 Press the window assembly onto the new or cleaned
quartz window.
8 Insert a new gasket [6, 7] and the window assembly [1]
into the cell body. Assure, that the gasket is on the
bottom.
&
'
(
)*
+
&
&
9dcdib^mi]Z\Vh`Zi
,
+
+VcY,
Y^[[ZgZci]daZY^VbZiZg
