Agilent 1260 Infinity DAD and MWD User Manual 39
Site Requirements and Specifications
2
Performance Specifications
Flow cells Standard: 13 µL volume, 10 mm cell path length
and 120 bar (1740 psi) pressure maximum
Semi-micro: 5 µL volume, 6 mm cell path length
and 120 bar (1740 psi) pressure maximum
Micro: 2 µL volume, 3 mm cell path length,
120 bar (1740 psi) pressure maximum
Semin-nano: 500 nL volume, 10 mm cell path
length and 50 bar (725 psi) pressure maximum
Nano: 80 nL volume, 10 mm cell path length and
50 bar (725 psi) pressure maximum
High pressure: 1.7 µL volume, 6 mm cell path
length and 400 bar (5800 psi) pressure
maximum
Prep SST: 3 mm cell path length and 120 bar
(1740 psi) pressure maximum
Prep Quartz:0.3 mm cell path length and 20 bar
(290 psi) pressure maximum
Prep Quartz: 0.06 mm cell path length and 20 bar
(290 psi) pressure maximum
See “Optimization Overview” on page 117
All flow cells are equipped with RFID tags that
hold cell typical information.
Time programmable Wavelength, polarity, peak width, lamp
bandwidth, autobalance, wavelength range,
threshold, spectra storage mode
Spectral tools Data analysis software for spectra evaluation,
including spectral libraries and peak purity
functions
Control and data
evaluation
Agilent ChemStation for LC (32-bit) For 1260 systems:
• Revision B.04.02 DSP2 or above
For 1100/1200 systems:
• Revision B.01.03 or above (G1315C/G1365C)
• Revision B.01.03 SR-2 / B.02.01 SR-2 or
above (G1315D/G1365D)
Local Control Agilent Instant Pilot (G4208A) For 1260 systems:
• B.02.11 or above
For other systems:
• B.02.09 or above
Analog outputs Recorder/integrator: 100 mV or 1 V, output
range 0.001 – 2 AU, two outputs
Tab le 13 Performance Specifications G1315C/D and G1365C/D
Type Specification Comments
