8 Agilent 6500 Series Q-TOF LC/MS Maintenance Guide
1 Basic Operation
Figure 2 6530 with Agilent Jet Stream Technology
For more details, see the site preparation guide that is sent to customers
before installation. If you move the instrument, you must follow and repeat the
steps detailed in the site preparation guide.
CDS cover
Service panel
Power switch
Flight tube
Front cover
