Getting Started Agilent 8164A Lightwave Measurement System
32 Agilent 8163A Lightwave Multimeter, Agilent 8164A Lightwave Measurement
System, & Agilent 8166A Lightwave Multichannel System, Fourth Edition
Agilent 8164A Lightwave
Measurement System
The Agilent 8164A Lightwave Measurement System mainframe has one large
and four slim module slots.
The system can host:
1 one back-loadable Tunable Laser module
2 and up to four front-loadable modules, of any combination of the following
types:
• Agilent 81689A Tunable Laser,
• Power Sensors, both dual and single,
• fixed wavelength Laser Sources, and
• Interface Modules for Optical Heads.
The front-loadable module slots support all modules designed for the HP 8153A
Lightwave Multimeter.
Figure 6 The Agilent 8164A Lightwave Measurement System Mainframe
