Agilent 8166A Lightwave
Multichannel System
The Agilent 8166A Lightwave Multichannel System has 17 slim module slots.
The system can host up to seventeen front-loadable modules, of any combination
of the following types:
• Agilent 81689A Tunable Laser,
• Power Sensors, both dual and single,
• fixed wavelength Laser Sources, and
• Interface Modules for Optical Heads.
The front-loadable module slots do not support any modules designed for the
HP 8153A Lightwave Multimeter, that is, modules with part numbers less than
81600.
Figure 7 The Agilent 8166A Lightwave Multichannel System Mainframe
