R29X Door Phone Administrator Guide
AKUVOX SMART INTERCOM www.akuvox.com
78
 Trigger Delay (Sec): set the relay trigger delay timing (Ranging from 1-10
Sec.) For example, if you set the delay time as “5” sec. then the relay will
not be triggered until 5 seconds after you press “unlock” tab.
 Hold Delay (Sec): set the relay hold delay timing (Ranging from 1-10 Sec.)
For example, if you set the hold delay time as “5” Sec. Then the relay will
resume the initial state after maintaining the triggered state for 5s.
 DTMF Option: select the number of DTMF digits for the door access
control (Ranging from 1-4 digits ) For example, you can select 1 digit
DTMF code or 2-digit DTMF code, etc., according to your need.
 DTMF: set the 1-digt DTMF code within range from ( 0-9 and *,#) if the
DTMF Option is set as “1-digit”.
 Multiple DTMF: set the DTMF code according to the DMTP Option setting.
For example, you are required to set the 3-digits DTMF code if DTMP
Option is set as 3-digits.
 Relay Status: relay status is low by default which means normally
closed(NC) If the relay status is high, then it is in Normally Open
status(NO).
 Relay Name: name the relay switch according to your need. For example,
you can name the relay switch according to where the relay switch is
located for convenience.
Note:
 Only the external devices connected to the relay switch need to be
powered by powered adapters as the relay switch does not supply
power.
