5. Radius Port set Radius server port
6. Radius Secret set Radius secret
7. Secondary Radius Server set Secondary Radius server IP address (optional)
8. Secondary Radius Port set Secondary Radius server port (optimal)
9. Secondary Radius Secret set Secondary Radius server secret (optional)
10. Click Submit
11. Click Save&Apply to apply
4) WPA-PSK/WPA2-PSK
WPA-PSK can be enabled by selecting WPA-PSK, WPA2-PSK for Authentication Mode.
The AES and TKIP are the two available options for Cipher Mode.
Figure 5-31 WPA-PSK/WPA2-PSK
Authentication Mode：WPA-PSK or WPA2-PSK
Cipher Mode： AES and TKIP can be choice.
Group Key Update Interval：By default, it is 66400
Pass Phrase：From 8-64 bits
WPA-PSK/WPA2-PSK Procedures:
1. Select Configuration -> Wireless -> Radio0 (2.4G) -> WLAN to edit “More…” WLAN,
and then select WLAN Security to access to security configuration page.
