Operating
105
0000010038-003- GB
Operating
Warning!
After changing a saw blade, always check that the riving knife is correctly
set.
Non-adherence to these points may lead to severe injuries of the opera-
tor!
• Select the riving knife according to the saw blade size and main
blade thickness
• Ensure that the riving knife thickness is min. 0.2 mm larger than the
main blade thickness
• The distance of the riving knife from the gear rim must be between 3
mm and 8 mm.
• The highest point of the riving knife must be set to between 0 and -2
mm beneath the topmost tooth.
• The riving knife must be at least 0.2 mm thicker than the main saw
blade.
Fig. 6-28 Adjusting the riving knife
