Operating
142
Operating
0000010038-003- GB
• Fit a new saw blade, paying attention to the rotational direction and hole
pattern: The circular saw blade (6) is in full contact with the flange (3) and
the shoulder on the circular saw blade must point to the contact surface.
• Turn in the screws (5) and tighten with a torque of 8.6 Nm.
• Proceed in the same manner for the other half of the adjustment unit.
Installation
• The clamping screw (1) is released.
• Fit the flange (3) vertically onto the holder (4) so that the spindle (2) enga-
ges in the threaded hole (7).
• Turn the spindle (2) counterclockwise with the Allen wrench. The flange (3)
is drawn onto the holder (4); the force applied must not increase.
• Continue turning the spindle (2), until the two circular saw blade halves are
in contact.
• Install the adjustment unit on the machine.
• Set the cutting width, see above.
• Slightly tighten the clamping screw (1).
Prohibitory!
Do not apply oil or grease!
