Cleaning/care
185
0000010038-003- GB
Cleaning/care
Lubrication, CNC rip fence
Quantity of lubricant
When lubricating, max. 5 strokes are required for applying the required 7 g of
lubricant.
The filled grease gun is included in the scope of delivery.
Motor driven rip fence (X axis)
The rail guide is relubricated via 2 lubricating nipples on the carriage.
The spindle for the X axis drive is lubricated via an additional lubricating nipple,
see figure!
Time interval :
After travel of 1500 m a message is shown on the display indicating that relub-
rication is necessary.
Lubrication is necessary every 12 months, irrespective of the distance tra-
velled.
Clearing the message
To temporarily clear the message: Actuate the STOP button.
After 10 adjustments or an interruption to the power, the message reappears!
To clear the message after lubrication: Press the START button 3x
Attention!
Please observe:
• Adhere to the precise lubricant quantity and time interval specified for
each relubrication cycle.
• Excessive lubrication due to short intervals and/or by too much lubri-
cant will lead to failures!
i
Note!
If you want to save time and money,
sign up for the annual Altendorf inspection, the "check-up" for your sliding
table saw.
The lubrication measures will be carried out by our maintenance staff
within the framework of the professional maintenance.
