Cleaning/care
186
Cleaning/care
0000010038-003- GB
Lubricating process:
• Move the rip fence to the position ~ 800 mm (in this position, it is also pos-
sible to access the lubricating nipple for the drive spindle).
• Turn off the main switch and secure against turning on again.
• Remove the protective cover and relubricate the lubricating nipples with the
provided grease gun.
• After lubrication, fit the cover plate!
• The machine is operational again after the error message is deleted.
Warning!
Danger of injury!
• Turn off the main switch before removing the cover plate!
Fig. 7-13 Lubricating nipple, X axis
[1] Lubricating nipple, rail guide
[2] Lubricating nipple, spindle drive
