Figure 4-55. Process Data Dialog
The Expert Process Data dialog will only be available in the EtherCAT Slave configuration editor if
the Enable Expert Settings option is activated. It provides another, more detailed, vision of the
process data, adding to what is presented in the Process Data tab. Furthermore, the download of the
PDO Assignment and the PDO Configuration can be activated in this dialog.
ATTENTION:
If the Slave doesn’t accept the PDO Configuration, it will stay in Pre-Operational state and none real
time data exchange will be possible
