MM-400A
3. Packaging
3-2
Item Model
Toroidal coil
*3
MB-800K-00 (approx. 250 mm in dia.)
1x sensitivity coil (with 800 mm bracket) (cable length
of 3 m)
MB-400K-00 (approx. 120 mm in dia.)
1x sensitivity coil (with 400 mm bracket) (cable length
of 3 m)
MB-45F-00 (45 mm in inner dia.)
10x sensitivity coil (mold type) (cable length of 3 m)
Toroidal coil
conversion cable
*3
SK-1193305 (cable length of 0.5 m)
Voltage detection
conversion cable
*4
SK-1193599 (cable length of 0.1 m)
RS-232C
communication cable
C06N-09MS-09FS-CROSS-WS15
(cable length of 1.5 m, 9-pin, male/female)
RS-485 connector L-04742-001 (Connector (D-Sub 9-pin, male))
LAN cable KB-FL6A-03BL (cable length of 3 m)
Communication software MA-725A-00-00
*1: Exclusively for the MM-400A. Do not use for other devices.
*2: For extending the MB-400M/800M.
*3: Toroidal coil conversion cable SK-1193305 is required for connecting to the
MM-400A.
*4: The conversion cable is required for connecting an old type voltage detection
cable (42265).
b. Exclusively for MM-400A-00-00
Item Model
I/O conversion cable
(used for conversion of
external I/O signals when
replacing the MM-370
series with MM-400A)
SK-1201954 (cable length of 0.15 m)
c. Exclusively for MM-400A-00-01
Shunt resistor
DS 500A/100MV (range between 25 A and 500 A)
DS 1000A/100MV (range between 50 A and 1000 A)
Current/force sensor
(put between electrodes for
measurement)
MA-770A-01 (4903 N (500 kgf) max.)
MA-771A-01 (9806 N (1,000 kgf) max.)
Replacement plate
*1
Z-04715-002 (with groove)
Z-04715-003 (flat)
Force sensor
(put between electrodes for
measurement)
MA-520B-00 (98.06 N (10 kgf) max.)
MA-521B-00 (980.6 N (100 kgf) max.)
MA-522B-00 (9806 N (1,000 kgf) max.)
To Next Page
