MM-400A
9. Measurement
9-7
(2) Measuring Displacement
(Force/displacement-equipped specification
function)
1) Connect the MM-400A to a power supply, and plug the displacement sensor
to the MM-400A. (For more information, refer to (2) b 1) and 2) in Chapter 6.)
2) Set the main power switch on the rear panel to the ON position (– side) to start
the MM-400A.
3) The MEASUREMENT 5(1) or MEASUREMENT 10 screen appears on the
display after a while.
To change or check the setting, touch MEAS to change it to PROG.
(Alternately switched by touching.)
To Next Page
