MM-400A
6. Installation and Connections
6-1
6. Installation and Connections
(1) Installing the MM-400A
1) Place the MM-400A on a stable surface.
Avoid locations where vibration is generated or the MM-400A rotates or
moves.
2) Connect the power cable to the power cable connector [INPUT POWER] on
the rear panel.
Ground the grounding terminal of the power cable. If not, measurement of the
MM-400A may be affected. Perform class D grounding work (Ministry of
Economy, Trade and Industry "Technical Standards for Electric Equipment").
When using the power cable (3 pin), connect it to the outlet which is the
grounding terminal is grounded (Fig. a). When using the 3-pin/2-pin conversion
adapter, ground the green/yellow-green grounding wire (Fig. b).
To Next Page
