(5) Code Table of Communication and USB Data
Code tables of communication and USB data are shown below.
1) Item number data table
Item No. Screen Item No. Screen
01 MEASUREMENT 14 SYSTEM SETUP
02 WAVEFORM 15 SEAM SETUP
03 CURRENT ALL CYCLE 16 COMPARATOR
04 FORCE ALL CYCLE 17 ENVELOPE
06 HISTORY 18 EXT INPUT/OUTPUT
07 HISTORY OUT OF LIM 21 PRINT
11 VIEW 22 COMMUNICATION
12 BASIC SETUP 23 USB
13 EXTEND SETUP 24 INTERNAL MEMORY
2) Measurement code table
Item
code
Item name Measured value Unit
Display
Range
Length
Display
Length
00 CURR PEAK 0.000
00.00
000.0
0.000 to 9.999
00.00 to 99.99
000.0 to 999.9
5 kA 2
01 CURR RMS
02 CURR AVG RMS
03 VOLT PEAK 0.00
00.0
0.00 to 9.99
00.0 to 99.9
4 V 1
04 VOLT RMS
05 VOLT AVG RMS
06 COND ANGLE 000 000 to 180 3 deg 3
07 POWER AVE 000.00 000.00 to 300.00 6 kW 2
08 RESISTANCE AVE 000.00 000.00 to 300.00 6 mOhm 4
09 WELD TIME 0000.0
0000
000.00
0000.0 to 3000.0
(in 0.5 CYC steps)
0000 to 3000
000.00 to 300.00
6
4
6
CYC
ms
3
2
10 WELD TIME TP 000.00 000.00 to 300.00 6 ms 2
11 WELD TIME TH
12 FLOW TIME 0000
000.00
0000 to 3000
000.00 to 300.00
4
6
ms 2
13 DIST INITIAL +00.000
+000.00
+0.0000
+00.000
-30.000 to +30.000
-300.00 to +300.00
-3.0000 to +3.0000
-30.000 to +30.000
7 mm
inch
2
4
14 DIST PULSE1
15 DIST PULSE2
16 DIST FINAL
17 DIST REAL TIME +00.000
+000.00
+0.0000
+00.000
+00.000
+000.00
+0.0000
+00.000
7 mm
inch
2
4
