MM-400A

8. Operation Screens

8-4

(2) Description of the Operation Screens

a. MENU Screen

Touching each item moves each screens. The screen varies according to the

product specifications and mode settings.

a-1. Normal: force/displacement equipped

a-2. Normal: standard (force/displacement not equipped)
