Amada WELD CHECKER MM-400A - (4) Interface of Other Connectors

MM-400A
10. Interface
10-9
(4) Interface of Other Connectors
a. Displacement sensor connector
[Refer to (2) Rear  in Chapter 4 “Name and Functions of Each Section.”]
1 +5V
2 A SIG
3 B SIG
4 _A SIG
5 GND
6 _B SIG
b. Displacement connector (Mitutoyo, Ono Sokki, KEYENCE, HEIDENHAIN,
10-pin)
[Refer to (2) Rear  in Chapter 4 “Name and Functions of Each Section.”]
01 +24V (KEYENCE)
02 +5V (Mitutoyo, Ono Sokki, HEIDENHAIN)
03 GND (Mitutoyo, Ono Sokki, KEYENCE, HEIDENHAIN)
04 A SIG (Ono Sokki)
05 B SIG (Ono Sokki)
06 A SIG (Mitutoyo, KEYENCE, HEIDENHAIN)
07 _A SIG (Mitutoyo, KEYENCE, HEIDENHAIN)
08 B SIG (Mitutoyo, KEYENCE, HEIDENHAIN)
09 _B SIG (Mitutoyo, KEYENCE, HEIDENHAIN)
10 Present position (KEYENCE)
c. Force sensor connector
[Refer to (2) Rear  in Chapter 4 “Name and Functions of Each Section.”]
A NC
B NC
C NC
D FORCE IN1(+)
E FORCE IN2(-)
F GND
G FG
H +5V
