Amada WELD CHECKER MM-400A - LG100-125 Type, Mitutoyo

MM-400A
16. Outline Drawing
16-4
c. LG100-125 Type, Mitutoyo
30.7
0.
6
20
(20.6)
8.6
3
4
6
1.7
114.793.6
226.5
(208.3)
φ15
0
-0.011
M14×0.5
43
φ14.7
Cable length=2m
26 min.
Stroke
(Screw for fixing Thrust Stem)
(Thread height)
