MM-400A
9. Measurement
9-1
9. Measurement
(1) Measuring Current (Current Flow Time)/Voltage
1) Connect the MM-400A to a power supply, and plug the toroidal coil and the
voltage detection cable to the MM-400A. (For more information, refer to (2) a
1) and 2) in Chapter 6.)
2) Set the main power switch on the rear panel to the ON position (– side) to start
the MM-400A.
3) The MEASUREMENT 5(1) or MEASUREMENT 10 screen appears on the
display after a while.
To Next Page
