MM-400A
12. Data Communication
12-68
Item
code
Item name Measured value Unit
Display
Range
Length
Display
Length
18 FORCE PEAK 00.00
000.0
0000
00.00 to 99.99
000.0 to 999.9
0000 to 9999
5
5
4
N
kgf
lbf
1
3
3
19 FORCE AVG1
20 FORCE AVG2
21 FORCE INITIAL
22 FORCE FINAL
23 FORCE REAL TIME 00.00
000.0
0000
00.00 to 99.99
000.0 to 999.9
0000 to 9999
5
5
4
24 FORCE TIME 00000 00000 to 30000 5 ms 2
25 EXT PEAK +0.000
+00.00
+000.0
+0000
-9.999 to +9.999
-99.99 to +99.99
-999.9 to +999.9
-9999 to +9999
6
6
6
5
V
N
kgf
lbf
degC
degF
Mpa
bar
psi
0
1
1
3
3
4
4
3
3
3
26 EXT AVE1
27 EXT AVE2
28 EXT INITIAL
29 EXT FINAL
30 EXT REAL TIME +0.000
+00.00
+000.0
+0000
-9.999 to +9.999
-99.99 to +99.99
-999.9 to +999.9
-9999 to +9999
6
6
6
5
31 EXT TIME 00000 00000 to 30000 5 ms 2
32 WELD COUNT 000000 L 6 0
33 GOOD COUNT 000000 000000 to 999999 6 0
34 No setting - No measured value 1 0
35 ENVELOPE - No measured value 1 0
3) Judgment code table
Code
Judgment
Display
Length
0 No judgment - 1
1 GOOD G
2 NG LOWER L
3 NG UPPER U
4 OVER O
5 NO CURR C
6 IMPULS I
7 PARITY P
8 COUNT UP -
9 No judgment -
