MM-400A
12. Data Communication
12-69
4) Upper/lower limit code table
Item
code
Item name
Measured value (*)
Unit
(*)
Display Range Length
00 CURR PEAK 000.000kA__
0000.00kA__
00000.0kA__
000.000 to 009.999kA__
0000.00 to 0099.99kA__
00000.0 to 00999.9KA__
11 kA__
01 CURR RMS
02 CURR AVG RMS
03 VOLT PEAK 0000.00V___
00000.0V___
0000.00 to 0009.99V___
00000.0 to 00099.9V___
11 V___
04 VOLT RMS
05 VOLT AVG RMS
06 COND ANGLE -------deg_ -------deg_ 11 deg_
07 POWER AVE 0000.00kW__ 0000.00 to 0300.00kW__ 11 kW
08 RESISTANCE AVE 0000.00mOhm 0000.00 to 0300.00mOhm 11 mOhm
09 WELD TIME 00000.0CYC 00000.0 to 03000.0CYC_
(in 0.5 CYC steps)
11 CYC_
0000000ms__ 0000000 to 0030000ms__ ms__
0000.00ms__ 0000.00 to 0300.00ms__
10 WELD TIME TP 00000.0ms__ 0000.00 to 0300.00ms__ 11 ms__
11 WELD TIME TH
12 FLOW TIME 0000000ms__ 0000000 to 0030000ms__ 11 ms__
13 DIST INITIAL +00.000mm__
+000.00mm__
+0.0000inch
+00.000inch
-30.000 to +30.000mm__
-300.00 to +300.00mm__
-3.0000 to +3.0000inch
-30.000 to +30.000inch
11 mm__
14 DIST PULSE1
15 DIST PULSE2
16 DIST FINAL
17 DIST REAL TIME -------mm__
-------inch
-------mm__
-------inch
18 FORCE PEAK 0000.00N___
00000.0N___
0000000N___
0000.00 to 0099.99N___
00000.0 to 00999.9N___
0000000 to 0009999N___
11 N___
kgf_
lbf_
19 FORCE AVG1
20 FORCE AVG2
21 FORCE INITIAL
22 FORCE FINAL
23 FORCE REAL TIME -------N___ -------N___
24 FORCE TIME -------ms__ -------ms__ 11 ms__
25 EXT PEAK +00.000degC
+000.00degC
+0000.0degC
+000000degC
-09.999 to +09.999degC
-099.99 to +099.99degC
-0999.9 to +0999.9degC
-009999 to +009999degC
11 ____
V___
N___
kgf_
lbf_
degC
degF
Mpa_
bar_
psi_
26 EXT AVE1
27 EXT AVE2
28 EXT INITIAL
29 EXT FINAL
30 EXT REAL TIME ----------- ----------- 11
31 EXT TIME -------ms__ -------ms__ 11 ms__
32 WELD COUNT ----------- ----------- 11
