MM-400A
12. Data Communication
12-28
2) EXTEND SETUP [Item No. 13]
 Writing request data for each schedule 001 to 127
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 001 001 to 127 3
5 Screen code S 1
6 Item No. 13 2
7 Delimiter : 1
DISPLACEMENT
8 LEVEL OUTPUT 1 +00.000mm -30.000 to +30.000mm__
-300.00 to +300.00mm__
-3.0000 to +3.0000inch
-30.000 to +30.000inch
11
*
9 Delimiter , 1
10 LEVEL OUTPUT 2 +00.000mm -30.000 to +30.000mm__
-300.00 to +300.00mm__
-3.0000 to +3.0000inch
-30.000 to +30.000inch
11
*
11 Delimiter , 1
12 LEVEL OUTPUT 3 +00.000mm -30.000 to +30.000mm__
-300.00 to +300.00mm__
-3.0000 to +3.0000inch
-30.000 to +30.000inch
11
*
13 Delimiter , 1
14 FINAL DELAY TIME 00000ms 00000 to 10000ms 7
15 Delimiter , 1
16 PULSE DELAY TIME 1 0000ms 0000 to 1000ms 6
17 Delimiter , 1
18 PULSE DELAY TIME 2 0000ms 0000 to 1000ms 6
19 Delimiter , 1
20 RESET DELAY TIME 0000ms 0000 to 1000ms 6
21 Delimiter , 1
FORCE
22 LEVEL OUTPUT 1 00000N__ 00000 to 09999N__
000.0 to 999.9N__
00.00 to 99.99N__
00000 to 09999kgf
000.0 to 999.9kgf
00.00 to 99.99kgf
00000 to 09999lbf
000.0 to 999.9lbf
00.00 to 99.99lbf
8
*
23 Delimiter , 1
