MM-400A
12. Data Communication
12-31
Item Display Range Length
52 TIME END 1 00000ms 00000 to 10000ms (in 10 ms steps) 7
53 Delimiter , 1
54 TIME BEGIN 2 00000ms 00000 to 10000ms (in 10 ms steps) 7
55 Delimiter , 1
56 TIME END 2 00000ms 00000 to 10000ms (in 10 ms steps) 7
57 Return code [CR] (0x0d) 1
58 Feed code [LF] (0x0a) 1
* A space falls into “_” for digit matching.
 Output data for each schedule 001 to 127
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 13 2
6 Delimiter : 1
8 “LEVEL OUTPUT 1” to 56 “TIME END 2” in EXTEND SETUP  Writing request data
for schedule
56 Return code [CR] (0x0d) 1
57 Feed code [LF] (0x0a) 1
 Writing request data common to all schedules (SCH.# 000)
Item Display Range Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 13 2
7 Delimiter : 1
DISPLACEMENT
8 INITIAL
MEASUREMENT
0 0: CURRENT START
1: EXTERNAL INPUT
1
9 Delimiter , 1
10 MEAS AFTER PULSE 0 0: CURRENT START
1: DELAY TIME
1
11 Delimiter , 1
12 FINAL
MEASUREMENT
0 0: DELAY TIME
1: EXTERNAL INPUT
1
13 Delimiter , 1
