MM-400A
12. Data Communication
12-32
Item Display Range Length
14 PULSE 2 RESET 0 0: OFF, 1: ON 1
15 Delimiter , 1
16 MEASUREMENT
MODE
0 0: REFERENCE
1: ABSOLUTE1
2: ABSOLUTE2
3: ABSOLUTE3
4: ABSOLUTE4
1
17 Delimiter , 1
18 SENSOR 0 0: Mitutoyo
1: Ono Sokki
2: KEYENCE
3: HEIDENHAIN
1
19 Delimiter , 1
20 SENSOR STEP 00.1um 00.1 to 10.0um 6
21 Delimiter , 1
22 POLARITY 0 0: FORWARD
1: REVERSE
1
23 Delimiter , 1
24 UNIT 0 0: mm
1: inch
1
25 Delimiter , 1
26 OUTPUT RANGE 0 0: 2.047
1: 8.191
2: 32.767
1
27 Delimiter , 1
FORCE
28 SENSOR 0 0: MA-520
1: MA-521
2: MA-522
3: MA-770
4: MA-771
5: RATED SETTING1
6: RATED SETTING2
1
29 Delimiter , 1
30 SPAN 0500 0500 to 1500 4
31 Delimiter , 1
32 RATED OUTPUT 0.750mV/V 0.750 to 2.000mV/V 9
33 Delimiter , 1
34 RATE 09806N__ 00490 to 09806N__
049.0 to 980.6N__
04.90 to 98.06N__
00050 to 01000kgf
005.0 to 100.0kgf
00.50 to 10.00kgf
00110 to 02204lbf
011.0 to 220.4lbf
01.10 to 22.04lbf
8
