MM-400A
12. Data Communication
12-47
7) EXT INPUT/OUTPUT [Item No. 18]
Writing request data (SCH.# 000)
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 18 2
7 Delimiter : 1
8 Input 1 0 (External input 1 to 6 code table) 1
9 Delimiter , 1
10 Input 2 1 (External input 1 to 6 code table) 1
11 Delimiter , 1
12 Input 3 2 (External input 1 to 6 code table) 1
13 Delimiter , 1
14 Input 4 3 (External input 1 to 6 code table) 1
15 Delimiter , 1
16 Input 5 4 (External input 1 to 6 code table) 1
17 Delimiter , 1
18 Input 6 8 (External input 1 to 6 code table) 1
19 Delimiter , 1
20 Input 7 1 (External input 7 to 8 code table) 1
21 Delimiter , 1
22 Input 8 3 (External input 7 to 8 code table) 1
23 Delimiter , 1
24 Output 1 -1 00 (External output 1 to 12 code table) 2
25 Delimiter , 1
26 Output 1 -2 62 (External output 1 to 12 code table) 2
27 Delimiter , 1
28 Output 1 -3 62 (External output 1 to 12 code table) 2
29 Delimiter , 1
30 Output 2 -1 01 (External output 1 to 12 code table) 2
31 Delimiter , 1
32 Output 2 -2 62 (External output 1 to 12 code table) 2
33 Delimiter , 1
34 Output 2 -3 62 (External output 1 to 12 code table) 2
35 Delimiter , 1
36 Output 3 -1 02 (External output 1 to 12 code table) 2
37 Delimiter , 1
To Next Page
